LF

Monitored LF frequencies
frequency call sign power location description
77.5 kHz DCF77 50 kW Mainflingen, Germany longwave time signal and standard-frequency
183 kHz Europe 1 2 MW Felsberg‑Berus, Germany French LW broadcast station [stream]
234 kHz RTL 2 MW Beidweiler, Luxemburg French LW broadcast station [stream]

MF

Monitored MF frequencies
frequency call sign power location description
1.933 MHz 01h–04h English G & GW [webSDR]

HF

Monitored HF frequencies
frequency CET language stations description
3.603 MHz Sundays 09h–11h Dutch PA & ON ZX-ronde [webSDR]
3.609 MHz 09h15–10h15 Dutch ON Belgisch ochtendnet [webSDR]
3.630 MHz 18h–20h Dutch PA & ON Nederlandstalig net [webSDR] [TeamSpeak]
3.630 MHz 00h–04h Dutch PA & ON Nachtuilen [webSDR]
3.697 MHz 01h–05h English G & GW [webSDR]
3.7475 MHz 18h15 German HB3 & HB9 Berner Runde [webSDR]
14.317 MHz 12h30 German HB9 Auslandschweizer Runde [webSDR]

VHF

Monitored VHF frequencies
frequency (MHz) shift (MHz) call sign access tone (Hz) CTCSS out (Hz) EchoLink location description
145.2375 ON0LIL 131.8 EchoLink gateway
145.2750 ON4RST Sint-Truiden UBA section Saffraanberg
145.3125 MLB Genk UBA section Midden‑Limburg
145.3875 ON7BB local hams from Opglabbeek
145.6625 -0.6 ON0NL 131.8 131.8 Peer repeater Noord‑Limburg
145.6500 -0.6 ON0LG 74.4 74.4 Seraing repeater Liège
145.7125 -0.6 ON0DST 131.8 131.8 179078 (31) Meldert-Lummen repeater Diest
145.7250 -0.6 PI3ZLB 71.9 71.9 Geleen repeater Geleen
145.7625 -0.6 ON0AN 67.0 67.0 Antwerpen repeater Antwerpen
145.7750 -0.6 ON0LB 131.8 & 1750 131.8 Vreren repeater Limburg [stream]
145.7875 -0.6 DB0WA 94.8 94.8 652436 Aachen repeater Aachen

UHF

Monitored UHF frequencies
frequency (MHz) shift (MHz) call sign access tone (Hz) CTCSS out (Hz) EchoLink location description
430.1250 +1.6 PI2NOS 430125 multiple locations; Sittard Dutch interconnected repeater network [bargraph] [map]
438.9000 -7.6 ON0LB 131.8 & 1750 131.8 195950 (33) Vreren repeater Limburg
439.0125 -7.6 ON0TB 131.8 3999
(41)
Robertville repeater Botrange
439.1000 -7.6 ON0TLO 131.8 131.8 429437 Scherpenheuvel repeater Tessenderlo
439.1500 -7.6 ON0LN 131.8 131.8 394137 (34) Ophoven, Oudsbergen analog repeater Limburg-Noord
(also digital in colocation)
439.3500 -7.6 ON0AN 131.8 45573 (21) Antwerpen repeater Antwerpen
Monitored UHF DVB-T1 & DVB‑T2 channels
frequency ch. pol. DVB‑T modulation Cell ID CNR SS RSS Q TV programs transmitter coverage
514 MHz 26 dir. V T2 64 QAM FEC ⅗ 27136 18 dB -81 dBm 23% 100% Das Erste, One, WDR, Arte Aachen-Stolberg, 40 kW map
538 MHz 29 dir. V T2 64 QAM FEC ⅗ 586 20 dB -80 dBm 25% 100% ZDF, ZDFinfo, ZDFneo, KiKA, 3sat Aachen-Stolberg, 20 kW map
570 MHz 33 dir. V T2 256 QAM FEC ½ 0 22 dB -77 dBm 28% 100% NPO1, NPO1, NPO3, L1, OB Sittard, 20 kW map
586 MHz 35 dir. V T2 64 QAM FEC ½ 28416 15 dB -85 dBm 18% 0% Phoenix, Tagesschau24, SWR, MDR, NDR Aachen-Stolberg, 20 kW map
666 MHz 45 H T1 16 QAM FEC ¾ 0 18 dB -81 dBm 23% 100% La Une, La Deux, La Trois/Ouftivi, Euronews Boncelles, Liège, 20 kW map PDF

DVB‑T equipment:

GPS, GLONASS & Galileo
frequency signal
1575.42 MHz L1C

Here is a live map of overhead GPS satellites.

X-band

Monitored satellite positions
position name origin of channels
5.0° W Eutelsat 5 W France
13.0° E Hot Bird Italy, Switzerland
19.2° E Astra 1 Germany, Spain
23.5° E Astra 3 Belgium, Netherlands
28.2° E Astra 2 UK

For lining out a satellite dish at your specific location, use this satellite look angle calculator.
